Introduction to Digital Forensics
University of Greenwich, Academic Year 2023-
Week 2: Disks, Storage and Imaging
Introduction
- (^) Physical Analysis
- (^) CHS and the make-up of a hard disk
- (^) Digital Investigation Issues
- (^) Raw Disk Images
- (^) Proving your image hasn’t been tampered with
Let's Get (old school) Physical
Hard-Disk Drive (HDD)
- (^) This is a Hard-Disk
- (^) This is a Disc
THIS IS NOT A HARD DISK!!!!!
One disk can pretend to be several disks
(partitions)
Several disks can pretend to be one disk (RAID)
Looking for RAID
- (^) A HDD can be a single storage device or it can operate with multiple other disks – Redundant Array of Independent (Inexpensive) Disks
- (^) You’ll have to rebuild the partitions from all/most disks
How is data saved on a ‘disk’?
Data
- (^) Binary is two conditions – something or nothing.
- (^) On or off, in or out, a hole or not a hole.
- (^) In electronics we can see it as current flowing through the circuit, or not.
- (^) On hard disks it is magnetically charge or not charged.
- (^) Imagine a metal surface that gets magnetic charge in places
Data
- (^) If the metal surface is good at storing magnetic charge
- (^) If we can precisely put AND remove charge from the metal surface, then we can effectively ‘punch’ and ‘un-punch’ a magnetic punch-card.
Inside the Disk - Prologue
- (^) If we have a track of magnetically sensitive material we can encode binary onto that track: 01000001 = 65 00100000 = 32 01100001 = 97 Or a Blob of Magnetic field
You spin me right round
- (^) However this is not an array of data, it is a track running around a circular shape. = 01000001 = 00100000 = 01100001 = 00000000 If the disk is spinning anti-clock The ‘head’ which reads the magnetic charge
CHS
- (^) There are 1 or more platters or ‘records’ – unlike a record player we read from both sides of the platter simultaneously: the Heads.
- (^) The Actuators are the mechanical arms that move to allow the heads to reach all points on the platter.
