Layout Tools

Layout Tools and Procedures

OBJECTIVES: As a result of this lesson, students will be able to accomplish the following objectives with 70% accuracy.

1. Identify and select appropriate tools for layout procedures in woodworking.
2. Use layout tools correctly and accurately when given a woodworking problem.
3. Read measurements within a 1/16".
4. Make a pattern using layout tools.

Essential Question: What are the common layout tools used in the Agriculture Mechanics lab?

Tape Measures

• Used for
  • Measuring
  • Divisions

Try Square

• Three purposes
  • Layout lines across grain of wood.
  • Test edge or end for squareness.
  • Test work for uniform width or thickness.

This is not a hammer!

Combination Square

• Used for
  • Measuring
  • Measuring and marking 90 and 45 degree angles.
  • Marking gage.
  • Level.

Speed Square

• Layout lines across grain

of wood.

• Measuring
• Laying out rafter angles.
• Laying out angles.

Sliding T-Bevel Square

• Main Use
  • Transferring angles to radial arm saw, compound miter saw, other tools, or from one board to another.

Folding Rule or Zig Zag Rule

• Use for
  • Measuring
  • Can be used to measure spans over head.
  • Not the most accurate tool.

Chalk Line

• Used to mark temporary

lines on walls, ceilings, or

boards.

Scratch Awl

• Use for marking wood or

metal.

Test your knowledge

Test your knowledge
