Daisy Chain Versus Collapsed Backbone Architecture
Objective
This lab compares the application performance of two different network
architectures; Daisy Chain and Collapsed Backbone Network. In the case
of collapsed backbone data network, there is a core switch in the basement
equipment room. The core switch is linked directly to a workgroup switch on
each floor. Another option is to link the switches in a daisy chain. In this case
the basement core switch is linked directly to the first floor switch, the first
floor switch is linked directly to the second floor switch, and so forth.
This lab shows the application latency introduced by connecting building
switches in different ways.
Overview
An office building has 10 floors, each having many users connected to a 10Base-T
workgroup switch. The users share an Oracle server and seven file and print
servers in the basement.
In Scenario 1, the switches on each floor are daisy chained to the core switch
in the basement. We will see that this daisy chain approach introduces high
application latency to users on the highest floor.
In Scenario 2, the daisy chain topology is retained, but the core switch is
moved to the fifth floor. We will see that this reduces latency on the highest
floor but increases it on the bottom floor.
In Scenario 3, the core switch is kept in the basement, but a collapsed-
backbone topology is used, in which the core switch in the basement is linked
directly to the workgroup switch on each floor.
Lab Instructions
Step 1:
1. Start IT Guru.
2. Select File Open…
3. Scroll down to the project named MultiStory_Building_LAN, select it and
click OK.
Docsity.com
pf3
pf4
pf5
pf8
pf9
pfa

Partial preview of the text

Download Daisy Chain, Collapsed Backbone Architecture - Computer Network - Lecture Handouts and more Lecture notes Computer Networks in PDF only on Docsity!

Daisy Chain Versus Collapsed Backbone Architecture

Objective

This lab compares the application performance of two different network architectures; Daisy Chain and Collapsed Backbone Network. In the case of collapsed backbone data network, there is a core switch in the basement equipment room. The core switch is linked directly to a workgroup switch on each floor. Another option is to link the switches in a daisy chain. In this case the basement core switch is linked directly to the first floor switch, the first floor switch is linked directly to the second floor switch, and so forth.

This lab shows the application latency introduced by connecting building switches in different ways.

Overview

An office building has 10 floors, each having many users connected to a 10Base-T workgroup switch. The users share an Oracle server and seven file and print servers in the basement.

In Scenario 1, the switches on each floor are daisy chained to the core switch in the basement. We will see that this daisy chain approach introduces high application latency to users on the highest floor.

In Scenario 2, the daisy chain topology is retained, but the core switch is moved to the fifth floor. We will see that this reduces latency on the highest floor but increases it on the bottom floor.

In Scenario 3, the core switch is kept in the basement, but a collapsed- backbone topology is used, in which the core switch in the basement is linked directly to the workgroup switch on each floor.

Lab Instructions

Step 1:

  1. Start IT Guru.
  2. Select File  Open…
  3. Scroll down to the project named MultiStory_Building_LAN , select it and click OK.

Several users are connected to a switch on each of the 10 floors. The users share an Oracle server and 7 File, Print, and Email servers in the basement.

Subnet: A subnet is a container used to create hierarchy of network levels. Double-click on the subnet named “7 File Print & Email Servers” to enter it. Here, we can see the servers clustered together. Right-click in the workspace and select Go To Parent Subnet to go to the upper subnet.

Step 3: View Results View the Oracle Application Response Time for users on Floors 1, 5, and 10.

  1. Right-click on the 95 Users Floor 10 object and select View Results.
  2. Expand Requesting Client Custom Application and select Application Response Time (sec).
  3. Select Show. This is the graph for the chatty oracle application response time which will be discussed later so do not close the graph window.
  4. Click Close in the View Results window.
  5. Right-click on the 50 Users Floor 5 object and select View Results.
  6. Choose Requesting Client Custom Application  Application Response Time (sec).
  7. Click Add and then click on the graph panel for the first graph you created. This is done to display statistics for users on different floors on the same panel.
  8. Repeat the same step 5 through 7 to add the application response time for users on floor 1 to the same graph.

Note: To toggle the graphs on and off, use the hide or show all graphs button.

Now we have the statistics for users on all floors on the same graph.

Your results should be similar to the graph above.

  • As we can see, the Application Response Time is close to 6 seconds for users on floor 10
  • It reduces as we move to the lower floors. Users on floor 1 have the least response times. This shows the amount of latency introduced by the switches.

Users on the top floor report high application response times. So the company decides to reduce the number of hops for the users on upper floors by moving the core switch and the servers to the fifth floor.

  1. Right-click on 95 Users Floor 10 and select Compare Results.
  2. Choose Requesting Client Custom Application  Application Response Time (sec).
  3. Click Show and then click Close in the View Results window.
  4. Repeat same steps for 50 Users Floor 5 and 70 Users Floor 1.
  • As expected, the Oracle application Response Time went down for users on floor 5 and floor 10.
  • But the users on floor 1 suffered an increase in response time.

The company decides to change the architecture from a Daisy Chain to a Collapsed Backbone network hoping to achieve the same application performance for all the users.

Conclusion

Task

  • Make a report of your recommendation to the firm on the choice of network architecture it should implement. Justify your choice by discussing the relative cabling costs and results of the graphs in your report.
