COMPUTER
NETWORKS
Lecture-
Review Lecture 36
Achieving Reliability
Packet Loss and Retransmission
Adaptive Transmission
Buffers, Flow Control, and Windows
Three Way Handshake
TCP Segment Format
Chapter 26
Network Address
Translation (NAT)
Network Address Translation
(NAT)
Requires device to perform packet translation
Implementations available Stand-alone hardware device IP router with NAT functionality embedded
NAT Details
Site Obtains a single valid IP address Assigns a private address to each computer Uses NAT box to connect to the internet
NAT
Translates address in IP datagrams
NAT Example
Site uses private network 10.0.0.0/
internally
First computer assigned 10.0.0.
Second computer assigned 10.0.0.
And so on...
Site obtains a valid IP address (e.g. 128.210.24.6)
Assume computer 10.0.0.1 sends to 128.211.134.4 Docsity.com
NAT Example
NAT translates the IP source address of the outgoing datagram
NAT translates the destination address of incoming datagram
Illustration of NAT Translation
Transparent to each end
Computer at site sends and receives datagrams normally
Computer in Internet receives datagrams from NAT box
Implementation of NAT
Summary
Congestion Control
TCP Segment Format
Network Address Translation
NAT Technology
Implementation of NAT
Basic Address Translation
